Broad industry applications across retail, logistics, and more
Multiple surface material options available
Pre-encoded for fast installation and deployment
High read sensitivity and fast encoding speed
Reliable labeling performance for small and hard-to-read items such as food and cosmetics
Customizable sizes and printing to suit different application scenarios and branding needs
Physical Specifications
Code No. | CE331540 |
Inlay Size | 15*40 mm |
Product Size | 20*46 mm |
Antenna Substrate Material | PET |
Surface Paper Materia | Coated paper |
Printing | Customized |
Color | White or customized |
Electrical Specifications
Protocol | ISO/IEC 18000-6C & EPCGlobal Class 1 Gen 2 |
RFID Operating Frequency | 865-868 MHz, 902-928 MHz |
Integrated Circuit [IC] | NXP Ucode X |
EPC Memory | 96-128 bits |
User Memory | 0-32 bits |
Unique TID | 96 bits |
Access Password | 32 bits |
Kill Password | 32 bits |
RFID Read Range | Up to 12 m |
Expected Read Cycles | 100,000 cycles |
Data Retention | 10 years |
Environmental Specifications
Operating Temperature | 5℃ ~60℃ |
Storage Temperature | 20℃ ~30℃ |
ESD | 2KV |
Shelf Life | 1 year in anti-static bag at 20~30℃ / 20%~60% RH (From the date of manufacturing) |
Packing Informations | |
Packing Format | Carton |
Inner Core Diameter | 3 inches |
Quantity Per Roll | 4000 pcs |
Roll Size | ≤205 mm |
Rolls Per Carton | 8 |
Carton Dimension | 440*440*135 mm |
