Century First RFID Bottle Tag – EasiCap B046, combining the classic B009 design with powerful RFID + EAS dual tech- nologies, is the ideal solution for protecting bottled wine and spirits. It enables real-time tracking, strengthens loss prevention, and improves inventory visibility. Versatile and reliable, it meets diverse retail needs with smart, secure performance.
RFID + EAS dual technologies boost loss prevention and enhance inventory visibility
Classic B009 design, innovative performance
Wider protection range, suitable for mainstream bottles
High compatibility, works with metal, foil, and other cap materials
Strong visual warning with reliable protection
Electrical Specification
| Protocol | ISO/IEC 18000-6C & EPC global Class 1 Gen 2 |
| Operating Frequency | 860-930MHz |
| Integrated Circuit [IC] | NXP U8 |
| EPC Memory | 128 bits |
| User Memory | 0 bits |
| Unique TID | 48 bits |
| Kill Password | 32 bits |
| Access Password | 32 bits |
| Read Range | Up to 5 m |
| Expected Read Cycles | 100,000 cycles |
| Data Retention | 10 years |
Physical Specification
| Code | B046 |
| Dimension | 90*64.5*75.5 mm |
| Material | PC+ABS |
| Range of Protection | Ø26-36 mm |
| Printing | Customized |
| Lock | Standard or Super |
| Color | Grey, Black or Customized |
| Packing Information | |
| Packing Format | Carton |
| Quantity Per Carton | 100 pcs |
| Carton Dimension | 58.5*39*17.5 cm |
| Weight Per Carton | 6.8 kg |
| Environmental Requirement | |
| Operating Temperature | 5～60℃ |
| Storage Temperature | 20～30℃ |
| ESD | 2KV |
| Shelf Life | "1 year in anti-static bag at 20～30℃ / |
| 20%～60RH (From the date of manufacture)" | |
